AirLink RX55 LTE-A NA
by Sierra Wireless

AirLink RX55 LTE-A NA

$829.00 - $829.00
$829.00
$829.00 - $829.00
$829.00

Key features

-Gigabit Ethernet, Serial (DB9), USB, Digital I/O
-GPS - 30 channel GNSS
-Environmental: MIL-STD-810-G, IP64, SAEJ1455, Class 1 Div 2 for hazardous areas
-Warranty - 3 year with option to 5 years

Product description

  • The AirLink® RX55 LTE-A NA is a rugged

  • compact
  • lowest power
  • LTE networking platform designed for both remote fixed and mobile applications �Econnecting critical remote assets and vehicles. The RX55 meet the demanding environmental and performance requirements of remote industrial and mobile applications
  • offering superior reliability and uninterrupted operation in harsh industrial
  • outdoor or vehicle environments. Vutility HotDrop Direct energy voltage amp

Contact manufacturer

Main Features
Network Technology
LTE Only
Other Features

Hardware

Main Features
Antenna
No
Battery
No
Display resolution
No
Ethernet ports
1
SIM type
Standard/Industrial Mini SIM (2FF)
USB ports
1
Voltage supply
No
Other Features
Accelerometer No
Z-Wave No
Audio No
Battery Safety No
Bluetooth No
Camera No
Dual SIM No
E911 No
eUICC No
Expansion Card Slots No
GNSS Yes
GPS Yes

Keyboard No
Magnetic Card Reader No
Printer No
RJ-11 No
Scanning Technology No
Serial Yes
Smart Card Reader No
Voice Transmission Capable No
Wifi Yes
Zigbee No

Software

Main Features
FoTA For Baseband/Modem
Software Update Capability
Verizon FoTA Solution (only)
FoTA Client Type
LWM2M
Operating System
Linux
Other Features
Developer Kit No
Diagnostics No
Security Level Security Level 1,(Regular OD devices. Minimum security requirements mandated.)
EMS No
MMS No
Remote Management Yes
SMS Capability No
WEA
(Wireless Emergency Alert)		 No
Persistent Prefix IPv6 No

Mobile Private Network Yes
Fixed Wireless Access
(FWA)		 No
Split Data Routing
(aka Dual APN)		 No
Multi-APN No
Global Capable No
Private Wireless
Network (On Site)		 No

Chassis

Main Features
Dimensions
119x85x34 in.
Weight
320 oz
Operating Temperature
-40 °C to +70 °C
Storage Temperature
-40 °C to +85 °C
Relative Humidity
MIL-STD-810G, test method 507.5 95% RH @ 60 C
Other Features
Rain & dust resistance No
Vehicle Mounting Yes

Network

Main Features
NAT
Yes
Routing Protocols
DMNR, RSR
Security Protocol
IPsec, OpenVPN
VPN Support
IPSEC, GRE, SSL
Numbershare
N - no Numbershare
Other Features
Fax capable No
Firewall No
UMTS Yes
LTE Band2 (1900 MHz), Band4 (1700 MHz), Band5 (850MHz), Band13 (700 MHz), Band66 (1700 MHz)
LTE Global / Roaming No
5G / Roaming No
5G Global / Roaming No
GPRS No
GSM No

Industry

Industrial / Manufacturing
Oil and Gas
Public Safety
Transportation
Utilities
