ICR-2041
by Advantech

ICR-2041

$310.00 - $310.00
$310.00
$310.00 - $310.00
$310.00

Key features

-For Industrial IoT and consumer focused high speed data applications
-Stand alone, DIN rail or wall mounting
-Enhanced memory to host custom software applications and a wide variety of protocols
-Ethernet, 1x Digital I/O

Product description

  • Industrial cellular router ICR-2041 is designed for wireless communication to enable connection of IP or serial devices to a cellular network. Industrial M2M and IoT applications include kiosks

  • industrial PCs
  • HMIs
  • traffic controllers
  • meters
  • UPS systems
  • and much more. The peak downlink data rate for LTE Cat.4 is approximately 150 Mbps. Also in the uplink
  • LTE Cat.4 provides a peak data rate of 50 Mbps. Vutility HotDrop Direct energy voltage amp

Contact manufacturer

Main Features
Network Technology
LTE with GSM/UMTS
Other Features

Hardware

Main Features
Antenna
No
Battery
CR2032X
Display resolution
No
Ethernet ports
1
SIM type
Standard/Industrial Micro SIM (3FF)
USB ports
0
Voltage supply
9 V - 48 V DC
Other Features
Accelerometer No
Z-Wave No
Audio No
Battery Safety No
Bluetooth No
Camera No
Dual SIM No
E911 No
eUICC No
Expansion Card Slots No
GNSS No
GPS No

Keyboard No
Magnetic Card Reader No
Printer No
RJ-11 No
Scanning Technology No
Serial No
Smart Card Reader No
Voice Transmission Capable No
Wifi No
Zigbee No

Software

Main Features
FoTA For Baseband/Modem
Software Update Capability
Verizon FoTA Solution and Non Verizon FoTA solution (combined)
FoTA Client Type
OMADM
Operating System
Linux
Other Features
Developer Kit No
Diagnostics No
Security Level Security Level 1,(Regular OD devices. Minimum security requirements mandated.)
EMS No
MMS No
Remote Management Yes
SMS Capability No
WEA
(Wireless Emergency Alert)		 No
Persistent Prefix IPv6 No

Mobile Private Network Yes
Fixed Wireless Access
(FWA)		 Yes
Split Data Routing
(aka Dual APN)		 No
Multi-APN No
Global Capable No
Private Wireless
Network (On Site)		 LTE Licensed

Chassis

Main Features
Dimensions
4.44x4.52x0.98 in.
Weight
0.761 lbs
Operating Temperature
-40 °F to 167 °F
Storage Temperature
-40 °C to 75 °F
Relative Humidity
95%
Other Features
Rain & dust resistance No
Vehicle Mounting No

Network

Main Features
NAT
yes
Routing Protocols
RIP, OSPF, BGP, Static routes
Security Protocol
HTTPS, SSH, SFTP
VPN Support
OpenVPN, IPSec with IKEv1 and IKEv2, EasyVPN, GRE, L2TP, PPTP, P2P
Numbershare
N - no Numbershare
Other Features
Fax capable No
Firewall Yes
UMTS No
LTE Band4 (1700 MHz), Band13 (700 MHz)
LTE Global / Roaming No
5G / Roaming No
5G Global / Roaming No
GPRS No
GSM No

Industry

Agricultural
Distribution
Financial Services
Healthcare
Hospitality
Industrial / Manufacturing
Oil and Gas
Transportation
